ECA UTP CAT 6 INDOOR CABLE
-7% OFF
CAT6 UTP indoor network cable with 23AWG x 4P CCA conductors and a durable grey PVC jacket. Supports fast, stable Ethernet connections for home and office LAN installations.
✓ In Stock
Out of Stock
For bulk orders, ISPs & businesses
Download Datasheet / Specs
Genuine product guaranteed
24/7 customer support
Upgrade your network infrastructure with this CAT6 UTP (Unshielded Twisted Pair) indoor cable, engineered for reliable, high-speed data transmission in residential and commercial settings.
Built with 23AWG x 4-pair CCA (Copper Clad Aluminum) conductors and HDPE-insulated cores, this cable delivers consistent signal performance while keeping conductor resistance low (max 78.8 ohm/km at 20°C). The color-coded pairs (Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown) follow standard wiring conventions for easy, error-free termination.
A tough grey PVC outer jacket (6.0mm ±0.20mm diameter) protects the cable while remaining flexible enough for easy routing through walls, conduits, and cable trays indoors.
Key Features:
Conductor: CCA, 23AWG x 4P, 1/0.52mm construction
Insulation: HDPE, 0.96mm diameter, standard 4-pair color coding
Jacket: PVC, grey, 6.0mm diameter
Rated: 75°C / 30V
Dielectric Strength: Min AC 1.5KV
Max Conductor Resistance: 78.8 ohm/km @ 20°C
Tensile Strength: 16.5 MPa (unaged), 14.2 MPa (aged)
Built with 23AWG x 4-pair CCA (Copper Clad Aluminum) conductors and HDPE-insulated cores, this cable delivers consistent signal performance while keeping conductor resistance low (max 78.8 ohm/km at 20°C). The color-coded pairs (Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown) follow standard wiring conventions for easy, error-free termination.
A tough grey PVC outer jacket (6.0mm ±0.20mm diameter) protects the cable while remaining flexible enough for easy routing through walls, conduits, and cable trays indoors.
Key Features:
Conductor: CCA, 23AWG x 4P, 1/0.52mm construction
Insulation: HDPE, 0.96mm diameter, standard 4-pair color coding
Jacket: PVC, grey, 6.0mm diameter
Rated: 75°C / 30V
Dielectric Strength: Min AC 1.5KV
Max Conductor Resistance: 78.8 ohm/km @ 20°C
Tensile Strength: 16.5 MPa (unaged), 14.2 MPa (aged)
